Wix Racing Oil Filters

The WIX line of racing oil filters features a heavy duty can and cover which provides up to 500 psi burst pressure protection for high performance racing engines. You won't collapse this filter as it features a Steel Fully Perforated Spiral Center Tube that has the highest collapse strength in the industry. Filter flow rates from 28 to 30 GPM provides plenty of flow for wide bearing clearances found in racing engines. Not intended for use in street vehicles.

WIX Racing Filters Cross Reference Guide (66k PDF)

Wix R Series-EA

Filter Number	Application	Thread Size	Filter Height	Filter OD	Media Type	Flow Rate GPM	Bypass Valve Setting	Anti-Drain Back Valve*
51060R	Chevy	13/16-16	5.17	3.6	T-71	28	None	Yes
51061R	Chevy	13/16-16	5.17	3.6	T-71	28	None	No
51069R	Chevy	13/16-16	4.33	3.6	T-71	28	None	No
51222R	Remote	1-1/2-12	6.21	4.6	T-71	28	18-22 PSI	No
51268R		1-1/8-16	5.21	3.6	T-10	30	None	No
51515R	Ford	3/4-16	5.17	3.6	T-71	28	8-11 PSI	Yes
51794R	Chevy	13/16-16	7.82	3.6	T-71	28	None	No
57003R	Remote	1-1/2-12	6.21	4.6	T-10	30	18-22 PSI	No
57007R		1-1/2-16	5.9	4.2	T-10	30	18-22 PSI	No
Advanced Performance Oil Filters use a media (T-10) that is rated at a Frazier air flow of approximately 267 CFM and is wire-backed. The unique wire-backing provides a very stable base for a media blend of fiberglass, polyester and cellulose. This media is resistant to high temperatures and water levels in the oil that can plug standard media types. Our Advanced Performance media (T-10) is designed to provide a high positive oil flow with low restriction.
High Efficiency Endurance Oil Filters use a media (T-71) rated at a Fraizer air flow of approximately 75 CFM. This media contains a higher resin content than our Advanced Performance Filters to trap and hold smaller contaminant's and provide higher efficiency.
